LOGO 200F
- Description
Description
LASER MARKING SYSTEM FOR SMALL ATELIERS AND SHOPS
LOGO 200F is the laser marking solution designed for jewelry stores, ateliers, and small workshops looking to combine precision, aesthetics, and practicality.
Created to meet the needs of professionals working with precious items, LOGO stands out for its versatility, easily fitting into small spaces thanks to its compact design and retractable sliding door, which ensures convenient access to the work area without sacrificing space.
Inside, it features a cutting-edge laser system capable of delivering precise engravings and outstanding finishes on a wide range of metals – both precious and non-precious. Everything is managed through a user-friendly software interface, intuitive even for less experienced users, with a guided process and integrated materials database to simplify every step of the workflow.
TECHNICAL DATA
| Laser source | MOPA – 20 W |
| Wavelenght | 1064 nm |
| Peak power | 14 kW |
| Max. pulse energy | 0,8 mJ |
| Pulse duration | 2 – 500ns |
| Workable materials | Steel, brass, aluminium, gold, silver |
| Max. marking volume | 100 x 100 x 100 mm (F160) |
| Power supply | 100/240 V AC – 50/60 Hz 1ph 150 W |
| Cooling system | Air |
| PC connectivity | RJ45 ethernet cable |
| Software | Developed by Sisma, compatible with Windows |
| Laser safety | Class 1- Safety interlocks |
| Dimensions (WxDxH) | 485 x 582 x 694 mm |
| Peso | 43,5 kg |
